Rcuxx::AltroRegister Struct Reference
[ALTRO interface classes]

#include <rcuxx/Altro.h>

Inherits Rcuxx::Register.

Inherited by Rcuxx::AltroADEVL, Rcuxx::AltroBCTHR, Rcuxx::AltroDPCF2, Rcuxx::AltroDPCFG, Rcuxx::AltroERSTR, Rcuxx::AltroKLCoeffs, Rcuxx::AltroPMADD, Rcuxx::AltroPMDTA, Rcuxx::AltroTRCFG, Rcuxx::AltroTRCNT, Rcuxx::AltroVFPED, Rcuxx::AltroZSTHR, and Rcuxx::BcRegister.

Collaboration diagram for Rcuxx::AltroRegister:

List of all members.

---

Detailed Description

Interface to an ALTRO (bus) register.

Note, that the access is implemented via the RcuIMEM and RcuRMEM interfaces, so this interface, and it's derived classes are completly general and does not need to be specialised for a particular back-end.

Public Member Functions
	AltroRegister (const char *name, unsigned int instr, Rcu &rcu, bool clear, bool submit, bool global=false, bool bcast=true)
virtual void	SetBroadcast ()
virtual void	SetAddress (unsigned int board, unsigned int chip, unsigned int channel=0)
virtual unsigned int	Write (unsigned int data)
virtual unsigned int	Read (unsigned int &data)
virtual unsigned int	WriteInstructions ()
virtual unsigned int	ReadInstructions ()
virtual void	Set ()
virtual void	Get ()
virtual unsigned int	Commit ()
virtual unsigned int	Update ()
virtual unsigned int	Encode ()
virtual void	Decode (unsigned int dat)
virtual void	Print () const
virtual bool	IsClearable () const
virtual bool	IsBroadcastable () const
Protected Attributes
bool	fClear
unsigned int	fInstr
Rcu &	fRcu
unsigned int	fAddress
bool	fGlobal
bool	fAllowBroadcast
unsigned int	fData

---

Constructor & Destructor Documentation

Rcuxx::AltroRegister::AltroRegister	(	const char *	name,
		unsigned int	instr,
		Rcu &	rcu,
		bool	clear,
		bool	submit,
		bool	global = false,
		bool	bcast = true
	)			[inline]

Constructor.

Parameters:

	name	Name
	instr	Instruction code
	imem	Instruction memory
	rmem	Result memory
	clear	Whether to enable Clear command
	submit	Whether to enable submit command
	global	Whether this is global
	bcast	Whether to allow broadcast

---

Member Function Documentation

void Rcuxx::AltroRegister::SetBroadcast

(

)

[inline, virtual]

Set to broadcast, if allowed.

Reimplemented in Rcuxx::BcRegister.

References fAddress, and fAllowBroadcast.

Referenced by Rcuxx::BcRegister::SetBroadcast().

void Rcuxx::AltroRegister::SetAddress	(	unsigned int	board,
		unsigned int	chip,
		unsigned int	channel = 0
	)			[inline, virtual]

Set target address.

Parameters:

	board	Board number (0x1f)
	chip	Chip number (0x7)
	channel	Channel number (0xf)

Reimplemented in Rcuxx::BcRegister.

References fAddress, and fGlobal.

Referenced by Rcuxx::BcRegister::SetAddress().

unsigned int Rcuxx::AltroRegister::Write

(

unsigned int

data

)

[inline, virtual]

Write data to register.

Parameters:

data

Data to put in register

Returns:

0 on success, error code otherwise

Reimplemented in Rcuxx::BcRegister.

References Rcuxx::RcuIMEM::Execute(), fAddress, fData, Rcuxx::RcuRMEM::FecWrite(), fInstr, fRcu, Rcuxx::Rcu::IMEM(), Rcuxx::Rcu::RMEM(), and WriteInstructions().

Referenced by Rcuxx::AltroTRCNT::Clear(), Rcuxx::AltroERSTR::Clear(), Commit(), and Rcuxx::BcRegister::Write().

unsigned int Rcuxx::AltroRegister::Read

(

unsigned int &

data

)

[inline, virtual]

Read value of register into data.

Parameters:

data

On return, value of register

Returns:

0 on success, error code otherwise

Reimplemented in Rcuxx::BcRegister.

References Rcuxx::RcuIMEM::Execute(), fAddress, Rcuxx::RcuRMEM::FecRead(), fInstr, fRcu, Rcuxx::Rcu::IMEM(), ReadInstructions(), and Rcuxx::Rcu::RMEM().

Referenced by Rcuxx::BcRegister::Read(), and Update().

unsigned int Rcuxx::AltroRegister::WriteInstructions

(

)

[inline, virtual]

Make write instructions and store them in imem.

Parameters:

imem

On return, instructions for writing

Returns:

false if the operation isn't allowed in current mode (broadcast) or this register is read-only.

References fAddress, fAllowBroadcast, fData, Rcuxx::RcuIMEM::FecWrite(), fInstr, fRcu, Rcuxx::Rcu::IMEM(), Rcuxx::Register::IsSubmitable(), Rcuxx::Rcu::kCannotBroadcast, and Rcuxx::Rcu::kNotWriteable.

Referenced by Write(), and Rcuxx::FmdRegister::WriteInstructions().

unsigned int Rcuxx::AltroRegister::ReadInstructions

(

)

[inline, virtual]

Make read instructions and store them in imem.

Parameters:

imem

On return, instructions for reading

Returns:

false if the operation isn't allowed in current mode (broadcast)

References fAddress, Rcuxx::RcuIMEM::FecRead(), fInstr, fRcu, Rcuxx::Rcu::IMEM(), and Rcuxx::Rcu::kCannotBroadcast.

Referenced by Read(), and Rcuxx::FmdRegister::ReadInstructions().

virtual void Rcuxx::AltroRegister::Set

(

)

[inline, virtual]

Set internal structures.

Reimplemented in Rcuxx::AltroBCTHR, Rcuxx::AltroDPCF2, Rcuxx::AltroDPCFG, Rcuxx::AltroKLCoeffs, Rcuxx::AltroPMADD, Rcuxx::AltroPMDTA, Rcuxx::AltroTRCFG, Rcuxx::AltroVFPED, Rcuxx::AltroZSTHR, Rcuxx::BcAC_TH, Rcuxx::BcAV_TH, Rcuxx::BcCSR0, Rcuxx::BcCSR2, Rcuxx::BcCSR3, Rcuxx::BcDC_TH, Rcuxx::BcDV_TH, Rcuxx::BcTEMP_TH, Rcuxx::BcTSMWORD, Rcuxx::BcUSRATIO, Rcuxx::FmdAL_ANA_I_TH, Rcuxx::FmdAL_ANA_U_TH, Rcuxx::FmdAL_DIG_I_TH, Rcuxx::FmdAL_DIG_U_TH, Rcuxx::FmdCalIter, Rcuxx::FmdClock, Rcuxx::FmdFLASH_I_TH, Rcuxx::FmdGTL_U_TH, Rcuxx::FmdHoldWait, Rcuxx::FmdL0Timeout, Rcuxx::FmdL1Timeout, Rcuxx::FmdRange, Rcuxx::FmdT1_TH, Rcuxx::FmdT1SENS_TH, Rcuxx::FmdT2_TH, Rcuxx::FmdT2SENS_TH, Rcuxx::FmdT3_TH, Rcuxx::FmdT4_TH, Rcuxx::FmdTopBottom, Rcuxx::FmdVA_REC_IM_TH, Rcuxx::FmdVA_REC_IP_TH, Rcuxx::FmdVA_REC_UM_TH, Rcuxx::FmdVA_REC_UP_TH, Rcuxx::FmdVA_SUP_IM_TH, Rcuxx::FmdVA_SUP_IP_TH, Rcuxx::FmdVA_SUP_UM_TH, and Rcuxx::FmdVA_SUP_UP_TH.

References fData.

Referenced by Commit(), and Encode().

virtual void Rcuxx::AltroRegister::Get

(

)

[inline, virtual]

Get internal structures.

Reimplemented in Rcuxx::AltroADEVL, Rcuxx::AltroBCTHR, Rcuxx::AltroDPCF2, Rcuxx::AltroDPCFG, Rcuxx::AltroERSTR, Rcuxx::AltroKLCoeffs, Rcuxx::AltroPMADD, Rcuxx::AltroPMDTA, Rcuxx::AltroTRCFG, Rcuxx::AltroTRCNT, Rcuxx::AltroVFPED, Rcuxx::AltroZSTHR, Rcuxx::BcAC, Rcuxx::BcAC_TH, Rcuxx::BcAV, Rcuxx::BcAV_TH, Rcuxx::BcCSR0, Rcuxx::BcCSR1, Rcuxx::BcCSR2, Rcuxx::BcCSR3, Rcuxx::BcDC, Rcuxx::BcDC_TH, Rcuxx::BcDSTBCNT, Rcuxx::BcDV, Rcuxx::BcDV_TH, Rcuxx::BcL1CNT, Rcuxx::BcL2CNT, Rcuxx::BcSCLKCNT, Rcuxx::BcTEMP, Rcuxx::BcTEMP_TH, Rcuxx::BcTSMWORD, Rcuxx::BcUSRATIO, Rcuxx::BcVersion, Rcuxx::FmdAL_ANA_I, Rcuxx::FmdAL_ANA_I_TH, Rcuxx::FmdAL_ANA_U, Rcuxx::FmdAL_ANA_U_TH, Rcuxx::FmdAL_DIG_I, Rcuxx::FmdAL_DIG_I_TH, Rcuxx::FmdAL_DIG_U, Rcuxx::FmdAL_DIG_U_TH, Rcuxx::FmdCalIter, Rcuxx::FmdClock, Rcuxx::FmdFLASH_I, Rcuxx::FmdFLASH_I_TH, Rcuxx::FmdGTL_U, Rcuxx::FmdGTL_U_TH, Rcuxx::FmdHoldWait, Rcuxx::FmdL0Timeout, Rcuxx::FmdL0Triggers, Rcuxx::FmdL1Timeout, Rcuxx::FmdL1Triggers, Rcuxx::FmdRange, Rcuxx::FmdStatus, Rcuxx::FmdT1, Rcuxx::FmdT1_TH, Rcuxx::FmdT1SENS, Rcuxx::FmdT1SENS_TH, Rcuxx::FmdT2, Rcuxx::FmdT2_TH, Rcuxx::FmdT2SENS, Rcuxx::FmdT2SENS_TH, Rcuxx::FmdT3, Rcuxx::FmdT3_TH, Rcuxx::FmdT4, Rcuxx::FmdT4_TH, Rcuxx::FmdTopBottom, Rcuxx::FmdVA_REC_IM, Rcuxx::FmdVA_REC_IM_TH, Rcuxx::FmdVA_REC_IP, Rcuxx::FmdVA_REC_IP_TH, Rcuxx::FmdVA_REC_UM, Rcuxx::FmdVA_REC_UM_TH, Rcuxx::FmdVA_REC_UP, Rcuxx::FmdVA_REC_UP_TH, Rcuxx::FmdVA_SUP_IM, Rcuxx::FmdVA_SUP_IM_TH, Rcuxx::FmdVA_SUP_IP, Rcuxx::FmdVA_SUP_IP_TH, Rcuxx::FmdVA_SUP_UM, Rcuxx::FmdVA_SUP_UM_TH, Rcuxx::FmdVA_SUP_UP, and Rcuxx::FmdVA_SUP_UP_TH.

Referenced by Decode(), and Update().

unsigned int Rcuxx::AltroRegister::Commit

(

)

[inline, virtual]

Commit stored values to hardware.

Returns:

0 on success, error code otherwise

Reimplemented from Rcuxx::Register.

References fData, Set(), and Write().

unsigned int Rcuxx::AltroRegister::Update

(

)

[inline, virtual]

Read from hardware to stored values.

Returns:

0 on success, error code otherwise

Reimplemented from Rcuxx::Register.

References fData, Get(), and Read().

Referenced by Rcuxx::BcMonitored::Monitor().

virtual unsigned int Rcuxx::AltroRegister::Encode

(

)

[inline, virtual]

Encode set value to register value.

Reimplemented from Rcuxx::Register.

References fData, and Set().

virtual void Rcuxx::AltroRegister::Decode

(

unsigned int

dat

)

[inline, virtual]

Decode register value to set value.

Reimplemented from Rcuxx::Register.

References fData, and Get().

void Rcuxx::AltroRegister::Print

(

)

const [inline, virtual]

Print contents of this register.

Reimplemented from Rcuxx::Register.

Reimplemented in Rcuxx::AltroADEVL, Rcuxx::AltroBCTHR, Rcuxx::AltroDPCF2, Rcuxx::AltroDPCFG, Rcuxx::AltroERSTR, Rcuxx::AltroKLCoeffs, Rcuxx::AltroPMADD, Rcuxx::AltroPMDTA, Rcuxx::AltroTRCFG, Rcuxx::AltroTRCNT, Rcuxx::AltroVFPED, Rcuxx::AltroZSTHR, Rcuxx::BcAC, Rcuxx::BcAC_TH, Rcuxx::BcAV, Rcuxx::BcAV_TH, Rcuxx::BcCSR0, Rcuxx::BcCSR1, Rcuxx::BcCSR2, Rcuxx::BcCSR3, Rcuxx::BcDC, Rcuxx::BcDC_TH, Rcuxx::BcDSTBCNT, Rcuxx::BcDV, Rcuxx::BcDV_TH, Rcuxx::BcL1CNT, Rcuxx::BcL2CNT, Rcuxx::BcMonitored, Rcuxx::BcSCLKCNT, Rcuxx::BcTEMP, Rcuxx::BcTEMP_TH, Rcuxx::BcThreshold, Rcuxx::BcTSMWORD, Rcuxx::BcUSRATIO, Rcuxx::BcVersion, Rcuxx::FmdClock, Rcuxx::FmdHoldWait, Rcuxx::FmdL0Timeout, Rcuxx::FmdL0Triggers, Rcuxx::FmdL1Timeout, Rcuxx::FmdL1Triggers, Rcuxx::FmdRange, Rcuxx::FmdStatus, and Rcuxx::FmdTopBottom.

References fData, fInstr, and Rcuxx::Register::fName.

Referenced by Rcuxx::FmdTopBottom::Print(), Rcuxx::FmdStatus::Print(), Rcuxx::FmdRange::Print(), Rcuxx::FmdL1Triggers::Print(), Rcuxx::FmdL1Timeout::Print(), Rcuxx::FmdL0Triggers::Print(), Rcuxx::FmdL0Timeout::Print(), Rcuxx::FmdHoldWait::Print(), Rcuxx::FmdClock::Print(), Rcuxx::BcUSRATIO::Print(), Rcuxx::BcTSMWORD::Print(), Rcuxx::BcThreshold::Print(), Rcuxx::BcTEMP_TH::Print(), Rcuxx::BcTEMP::Print(), Rcuxx::BcSCLKCNT::Print(), Rcuxx::BcMonitored::Print(), Rcuxx::BcL2CNT::Print(), Rcuxx::BcL1CNT::Print(), Rcuxx::BcDV_TH::Print(), Rcuxx::BcDV::Print(), Rcuxx::BcDSTBCNT::Print(), Rcuxx::BcDC_TH::Print(), Rcuxx::BcDC::Print(), Rcuxx::BcCSR3::Print(), Rcuxx::BcCSR2::Print(), Rcuxx::BcCSR1::Print(), Rcuxx::BcCSR0::Print(), Rcuxx::BcAV_TH::Print(), Rcuxx::BcAV::Print(), Rcuxx::BcAC_TH::Print(), Rcuxx::BcAC::Print(), Rcuxx::AltroZSTHR::Print(), Rcuxx::AltroVFPED::Print(), Rcuxx::AltroTRCNT::Print(), Rcuxx::AltroTRCFG::Print(), Rcuxx::AltroPMDTA::Print(), Rcuxx::AltroPMADD::Print(), Rcuxx::AltroKLCoeffs::Print(), Rcuxx::AltroERSTR::Print(), Rcuxx::AltroDPCFG::Print(), Rcuxx::AltroDPCF2::Print(), Rcuxx::AltroBCTHR::Print(), and Rcuxx::AltroADEVL::Print().

virtual bool Rcuxx::AltroRegister::IsClearable

(

)

const [inline, virtual]

Whether we got Clear.

Reimplemented from Rcuxx::Register.

References fClear.

virtual bool Rcuxx::AltroRegister::IsBroadcastable

(

)

const [inline, virtual]

Whether this can be broadcast.

Reimplemented from Rcuxx::Register.

References fAllowBroadcast.

Referenced by Rcuxx::BcRegister::I2CWrite().

---

Member Data Documentation

bool Rcuxx::AltroRegister::fClear [protected]

Can clear.

Reimplemented from Rcuxx::Register.

Reimplemented in Rcuxx::BcCSR1.

Referenced by IsClearable().

unsigned int Rcuxx::AltroRegister::fInstr [protected]

Instruction number.

Referenced by Rcuxx::BcRegister::BcRegister(), Rcuxx::BcRegister::I2CRead(), Rcuxx::BcRegister::I2CWrite(), Print(), Read(), ReadInstructions(), Write(), and WriteInstructions().

Rcu& Rcuxx::AltroRegister::fRcu [protected]

Reference to RCU.

Referenced by Rcuxx::BcRegister::I2CRead(), Rcuxx::BcRegister::I2CWrite(), Read(), ReadInstructions(), Write(), and WriteInstructions().

unsigned int Rcuxx::AltroRegister::fAddress [protected]

Address.

Referenced by Rcuxx::AltroTRCNT::Clear(), Rcuxx::BcRegister::I2CRead(), Rcuxx::BcRegister::I2CWrite(), Read(), ReadInstructions(), Rcuxx::BcRegister::SetAddress(), SetAddress(), Rcuxx::BcRegister::SetBroadcast(), SetBroadcast(), Write(), and WriteInstructions().

bool Rcuxx::AltroRegister::fGlobal [protected]

Whether it's global.

Referenced by SetAddress().

bool Rcuxx::AltroRegister::fAllowBroadcast [protected]

Whether it allows broad cast.

Referenced by IsBroadcastable(), SetBroadcast(), and WriteInstructions().

unsigned int Rcuxx::AltroRegister::fData [protected]

Data cache.

Referenced by Rcuxx::BcTEMP_TH::Centigrade(), Rcuxx::BcTEMP::Centigrade(), Rcuxx::FmdT2::Centigrades(), Rcuxx::FmdT1::Centigrades(), Rcuxx::FmdT4::Centrigrades(), Rcuxx::FmdT3::Centrigrades(), Rcuxx::FmdT2SENS::Centrigrades(), Rcuxx::FmdT1SENS::Centrigrades(), Rcuxx::FmdL1Timeout::Clocks(), Rcuxx::FmdL0Timeout::Clocks(), Rcuxx::FmdHoldWait::Clocks(), Commit(), Rcuxx::BcSCLKCNT::Counts(), Rcuxx::BcL2CNT::Counts(), Rcuxx::BcL1CNT::Counts(), Rcuxx::BcDSTBCNT::Counts(), Rcuxx::BcMonitored::Current(), Rcuxx::BcMonitored::CurrentNatural(), Decode(), Encode(), Rcuxx::FmdVA_SUP_UP_TH::Get(), Rcuxx::FmdVA_SUP_UP::Get(), Rcuxx::FmdVA_SUP_UM_TH::Get(), Rcuxx::FmdVA_SUP_UM::Get(), Rcuxx::FmdVA_SUP_IP_TH::Get(), Rcuxx::FmdVA_SUP_IP::Get(), Rcuxx::FmdVA_SUP_IM_TH::Get(), Rcuxx::FmdVA_SUP_IM::Get(), Rcuxx::FmdVA_REC_UP_TH::Get(), Rcuxx::FmdVA_REC_UP::Get(), Rcuxx::FmdVA_REC_UM_TH::Get(), Rcuxx::FmdVA_REC_UM::Get(), Rcuxx::FmdVA_REC_IP_TH::Get(), Rcuxx::FmdVA_REC_IP::Get(), Rcuxx::FmdVA_REC_IM_TH::Get(), Rcuxx::FmdVA_REC_IM::Get(), Rcuxx::FmdTopBottom::Get(), Rcuxx::FmdT4_TH::Get(), Rcuxx::FmdT4::Get(), Rcuxx::FmdT3_TH::Get(), Rcuxx::FmdT3::Get(), Rcuxx::FmdT2SENS_TH::Get(), Rcuxx::FmdT2SENS::Get(), Rcuxx::FmdT2_TH::Get(), Rcuxx::FmdT2::Get(), Rcuxx::FmdT1SENS_TH::Get(), Rcuxx::FmdT1SENS::Get(), Rcuxx::FmdT1_TH::Get(), Rcuxx::FmdT1::Get(), Rcuxx::FmdStatus::Get(), Rcuxx::FmdRange::Get(), Rcuxx::FmdL1Triggers::Get(), Rcuxx::FmdL1Timeout::Get(), Rcuxx::FmdL0Triggers::Get(), Rcuxx::FmdL0Timeout::Get(), Rcuxx::FmdHoldWait::Get(), Rcuxx::FmdGTL_U_TH::Get(), Rcuxx::FmdGTL_U::Get(), Rcuxx::FmdFLASH_I_TH::Get(), Rcuxx::FmdFLASH_I::Get(), Rcuxx::FmdClock::Get(), Rcuxx::FmdCalIter::Get(), Rcuxx::FmdAL_DIG_U_TH::Get(), Rcuxx::FmdAL_DIG_U::Get(), Rcuxx::FmdAL_DIG_I_TH::Get(), Rcuxx::FmdAL_DIG_I::Get(), Rcuxx::FmdAL_ANA_U_TH::Get(), Rcuxx::FmdAL_ANA_U::Get(), Rcuxx::FmdAL_ANA_I_TH::Get(), Rcuxx::FmdAL_ANA_I::Get(), Rcuxx::BcVersion::Get(), Rcuxx::BcUSRATIO::Get(), Rcuxx::BcTSMWORD::Get(), Rcuxx::BcTEMP_TH::Get(), Rcuxx::BcTEMP::Get(), Rcuxx::BcSCLKCNT::Get(), Rcuxx::BcL2CNT::Get(), Rcuxx::BcL1CNT::Get(), Rcuxx::BcDV_TH::Get(), Rcuxx::BcDV::Get(), Rcuxx::BcDSTBCNT::Get(), Rcuxx::BcDC_TH::Get(), Rcuxx::BcDC::Get(), Rcuxx::BcCSR3::Get(), Rcuxx::BcCSR2::Get(), Rcuxx::BcCSR1::Get(), Rcuxx::BcCSR0::Get(), Rcuxx::BcAV_TH::Get(), Rcuxx::BcAV::Get(), Rcuxx::BcAC_TH::Get(), Rcuxx::BcAC::Get(), Rcuxx::AltroZSTHR::Get(), Rcuxx::AltroVFPED::Get(), Rcuxx::AltroTRCNT::Get(), Rcuxx::AltroTRCFG::Get(), Rcuxx::AltroPMDTA::Get(), Rcuxx::AltroPMADD::Get(), Rcuxx::AltroKLCoeffs::Get(), Rcuxx::AltroERSTR::Get(), Rcuxx::AltroDPCFG::Get(), Rcuxx::AltroDPCF2::Get(), Rcuxx::AltroBCTHR::Get(), Rcuxx::AltroADEVL::Get(), Rcuxx::FmdT4_TH::GetNatural(), Rcuxx::FmdT3_TH::GetNatural(), Rcuxx::FmdT2SENS_TH::GetNatural(), Rcuxx::FmdT2_TH::GetNatural(), Rcuxx::FmdT1SENS_TH::GetNatural(), Rcuxx::FmdT1_TH::GetNatural(), Rcuxx::FmdVA_SUP_IP_TH::MiliAmps(), Rcuxx::FmdVA_SUP_IP::MiliAmps(), Rcuxx::FmdVA_SUP_IM_TH::MiliAmps(), Rcuxx::FmdVA_SUP_IM::MiliAmps(), Rcuxx::FmdVA_REC_IP_TH::MiliAmps(), Rcuxx::FmdVA_REC_IP::MiliAmps(), Rcuxx::FmdVA_REC_IM_TH::MiliAmps(), Rcuxx::FmdVA_REC_IM::MiliAmps(), Rcuxx::FmdFLASH_I_TH::MiliAmps(), Rcuxx::FmdFLASH_I::MiliAmps(), Rcuxx::FmdAL_DIG_I_TH::MiliAmps(), Rcuxx::FmdAL_DIG_I::MiliAmps(), Rcuxx::FmdAL_ANA_I_TH::MiliAmps(), Rcuxx::FmdAL_ANA_I::MiliAmps(), Rcuxx::BcDC_TH::MiliAmps(), Rcuxx::BcDC::MiliAmps(), Rcuxx::BcAC_TH::MiliAmps(), Rcuxx::BcAC::MiliAmps(), Rcuxx::FmdVA_SUP_UP_TH::MiliVolts(), Rcuxx::FmdVA_SUP_UP::MiliVolts(), Rcuxx::FmdVA_SUP_UM_TH::MiliVolts(), Rcuxx::FmdVA_SUP_UM::MiliVolts(), Rcuxx::FmdVA_REC_UP_TH::MiliVolts(), Rcuxx::FmdVA_REC_UP::MiliVolts(), Rcuxx::FmdVA_REC_UM_TH::MiliVolts(), Rcuxx::FmdVA_REC_UM::MiliVolts(), Rcuxx::FmdGTL_U_TH::MiliVolts(), Rcuxx::FmdGTL_U::MiliVolts(), Rcuxx::FmdAL_DIG_U_TH::MiliVolts(), Rcuxx::FmdAL_DIG_U::MiliVolts(), Rcuxx::FmdAL_ANA_U_TH::MiliVolts(), Rcuxx::FmdAL_ANA_U::MiliVolts(), Rcuxx::BcDV_TH::MiliVolts(), Rcuxx::BcDV::MiliVolts(), Rcuxx::BcAV_TH::MiliVolts(), Rcuxx::BcAV::MiliVolts(), Rcuxx::BcTSMWORD::Number(), Rcuxx::FmdL1Triggers::Print(), Rcuxx::FmdL1Timeout::Print(), Rcuxx::FmdL0Triggers::Print(), Rcuxx::FmdL0Timeout::Print(), Rcuxx::FmdHoldWait::Print(), Rcuxx::BcUSRATIO::Print(), Rcuxx::BcTSMWORD::Print(), Rcuxx::BcThreshold::Print(), Rcuxx::BcSCLKCNT::Print(), Rcuxx::BcMonitored::Print(), Rcuxx::BcL2CNT::Print(), Rcuxx::BcL1CNT::Print(), Rcuxx::BcDSTBCNT::Print(), Print(), Rcuxx::BcUSRATIO::Ratio(), Rcuxx::FmdL1Triggers::Recieved(), Rcuxx::FmdL0Triggers::Recieved(), Rcuxx::FmdVA_SUP_UP_TH::Set(), Rcuxx::FmdVA_SUP_UM_TH::Set(), Rcuxx::FmdVA_SUP_IP_TH::Set(), Rcuxx::FmdVA_SUP_IM_TH::Set(), Rcuxx::FmdVA_REC_UP_TH::Set(), Rcuxx::FmdVA_REC_UM_TH::Set(), Rcuxx::FmdVA_REC_IP_TH::Set(), Rcuxx::FmdVA_REC_IM_TH::Set(), Rcuxx::FmdTopBottom::Set(), Rcuxx::FmdT4_TH::Set(), Rcuxx::FmdT3_TH::Set(), Rcuxx::FmdT2SENS_TH::Set(), Rcuxx::FmdT2_TH::Set(), Rcuxx::FmdT1SENS_TH::Set(), Rcuxx::FmdT1_TH::Set(), Rcuxx::FmdRange::Set(), Rcuxx::FmdL1Timeout::Set(), Rcuxx::FmdL0Timeout::Set(), Rcuxx::FmdHoldWait::Set(), Rcuxx::FmdGTL_U_TH::Set(), Rcuxx::FmdFLASH_I_TH::Set(), Rcuxx::FmdClock::Set(), Rcuxx::FmdCalIter::Set(), Rcuxx::FmdAL_DIG_U_TH::Set(), Rcuxx::FmdAL_DIG_I_TH::Set(), Rcuxx::FmdAL_ANA_U_TH::Set(), Rcuxx::FmdAL_ANA_I_TH::Set(), Rcuxx::BcUSRATIO::Set(), Rcuxx::BcTSMWORD::Set(), Rcuxx::BcTEMP_TH::Set(), Rcuxx::BcDV_TH::Set(), Rcuxx::BcDC_TH::Set(), Rcuxx::BcCSR3::Set(), Rcuxx::BcCSR2::Set(), Rcuxx::BcCSR0::Set(), Rcuxx::BcAV_TH::Set(), Rcuxx::BcAC_TH::Set(), Rcuxx::AltroZSTHR::Set(), Rcuxx::AltroVFPED::Set(), Rcuxx::AltroTRCFG::Set(), Set(), Rcuxx::AltroPMDTA::Set(), Rcuxx::AltroPMADD::Set(), Rcuxx::AltroKLCoeffs::Set(), Rcuxx::AltroDPCFG::Set(), Rcuxx::AltroDPCF2::Set(), Rcuxx::AltroBCTHR::Set(), Rcuxx::FmdT4_TH::SetCentigrade(), Rcuxx::FmdT3_TH::SetCentigrade(), Rcuxx::FmdT2SENS_TH::SetCentigrade(), Rcuxx::FmdT2_TH::SetCentigrade(), Rcuxx::FmdT1SENS_TH::SetCentigrade(), Rcuxx::FmdT1_TH::SetCentigrade(), Rcuxx::BcTEMP_TH::SetCentigrade(), Rcuxx::FmdL1Timeout::SetClocks(), Rcuxx::FmdL0Timeout::SetClocks(), Rcuxx::FmdHoldWait::SetClocks(), Rcuxx::FmdVA_SUP_IP_TH::SetMiliAmps(), Rcuxx::FmdVA_SUP_IM_TH::SetMiliAmps(), Rcuxx::FmdVA_REC_IP_TH::SetMiliAmps(), Rcuxx::FmdVA_REC_IM_TH::SetMiliAmps(), Rcuxx::FmdFLASH_I_TH::SetMiliAmps(), Rcuxx::FmdAL_DIG_I_TH::SetMiliAmps(), Rcuxx::FmdAL_ANA_I_TH::SetMiliAmps(), Rcuxx::BcDC_TH::SetMiliAmps(), Rcuxx::BcAC_TH::SetMiliAmps(), Rcuxx::FmdVA_SUP_UP_TH::SetMiliVolts(), Rcuxx::FmdVA_SUP_UM_TH::SetMiliVolts(), Rcuxx::FmdVA_REC_UP_TH::SetMiliVolts(), Rcuxx::FmdVA_REC_UM_TH::SetMiliVolts(), Rcuxx::FmdGTL_U_TH::SetMiliVolts(), Rcuxx::FmdAL_DIG_U_TH::SetMiliVolts(), Rcuxx::FmdAL_ANA_U_TH::SetMiliVolts(), Rcuxx::BcDV_TH::SetMiliVolts(), Rcuxx::BcAV_TH::SetMiliVolts(), Rcuxx::BcTSMWORD::SetNumber(), Rcuxx::BcUSRATIO::SetRatio(), Rcuxx::BcThreshold::SetThreshold(), Rcuxx::BcThreshold::Threshold(), Rcuxx::BcThreshold::ThresholdNatural(), Update(), Write(), and WriteInstructions().

---

The documentation for this struct was generated from the following file:

• AltroRegister.h
