Rcuxx::RcuMemory Class Reference
[RCU interface classes]

#include <rcuxx/Rcu.h>

Inheritance diagram for Rcuxx::RcuMemory:

Collaboration diagram for Rcuxx::RcuMemory:

List of all members.

---

Detailed Description

Interface to the RCU memory banks.

Public Types
typedef std::vector< unsigned int >	Cache_t
Public Member Functions
	RcuMemory (Rcu &rcu, const char *name, unsigned int base, unsigned int size, unsigned int max, bool commit, RcuCommand *clear=0, RcuCommand *exec=0, RcuCommand *abort=0)
virtual	~RcuMemory ()
virtual unsigned int	Update ()
virtual unsigned int	Commit ()
virtual unsigned int	Update (size_t off, size_t n)
virtual unsigned int	Commit (size_t off, size_t n)
virtual unsigned int	Clear ()
virtual unsigned int	Exec (unsigned int arg)
virtual unsigned int	Abort ()
virtual bool	Load (std::istream &in)
virtual bool	Save (std::ostream &out)
virtual void	Zero ()
unsigned int	Size () const
unsigned int	Max () const
const Cache_t &	Data () const
Cache_t &	Data ()
void	Set (size_t off, size_t n, unsigned int *d)
void	Get (size_t off, size_t n, unsigned int *d)
unsigned int	Base () const
virtual void	Print () const
const std::string &	Name () const
virtual bool	IsWriteable () const
virtual bool	IsClearable () const
virtual bool	IsExecutable () const
Protected Attributes
Rcu &	fRcu
std::string	fName
unsigned int	fBase
Cache_t	fData
unsigned int	fSize
unsigned int	fMax
bool	fWriteable
RcuCommand *	fClear
RcuCommand *	fExec
RcuCommand *	fAbort

---

Member Typedef Documentation

typedef std::vector<unsigned int> Rcuxx::RcuMemory::Cache_t

Type of cache.

---

Constructor & Destructor Documentation

Rcuxx::RcuMemory::RcuMemory	(	Rcu &	rcu,
		const char *	name,
		unsigned int	base,
		unsigned int	size,
		unsigned int	max,
		bool	commit,
		RcuCommand *	clear = 0,
		RcuCommand *	exec = 0,
		RcuCommand *	abort = 0
	)			[inline]

Constructor.

Parameters:

	rcu	Reference to RCU
	name	Name of the memory
	base	Base address
	size	Number of words in the memory
	max	Maximum value of words in the memory
	commit	Whether the memory is writeable
	clear	Command to clear
	exec	Command to execute
	abort	Command to abort execution.

References Zero().

virtual Rcuxx::RcuMemory::~RcuMemory

(

)

[inline, virtual]

Destructor.

---

Member Function Documentation

virtual unsigned int Rcuxx::RcuMemory::Update

(

)

[inline, virtual]

Update the cache.

Returns:

0 on success, error code otherwise

Reimplemented in Rcuxx::RcuACL, Rcuxx::RcuDMEM, and Rcuxx::RcuSTATUS.

Examples:

rwr_trcfg.cxx.

References fSize.

Referenced by Rcuxx::RcuRMEM::FecCommand(), Rcuxx::RcuRMEM::FecRead(), Rcuxx::RcuRMEM::FecWrite(), Rcuxx::RcuSTATUS::Update(), Rcuxx::RcuRegister::Update(), Rcuxx::RcuACTFEC::Update(), and Rcuxx::RcuACL::Update().

virtual unsigned int Rcuxx::RcuMemory::Commit

(

)

[inline, virtual]

Commit to the RCU.

Returns:

0 on success, error code otherwise

Reimplemented in Rcuxx::RcuACL, and Rcuxx::RcuDMEM.

References fSize.

Referenced by Rcuxx::RcuRegister::Commit(), Rcuxx::RcuDMEM::Commit(), Rcuxx::RcuACTFEC::Commit(), Rcuxx::RcuACL::Commit(), and Rcuxx::RcuIMEM::Execute().

unsigned int Rcuxx::RcuMemory::Update	(	size_t	off,
		size_t	n
	)			[inline, virtual]

Update the cache (restricted).

Parameters:

	off	Where to start reading
	n	How many words to read

Returns:

0 on success, error code otherwise

Reimplemented in Rcuxx::RcuACL, Rcuxx::RcuDMEM, and Rcuxx::RcuSTATUS.

References fBase, fData, fRcu, fSize, and Rcuxx::Rcu::ReadMemory().

unsigned int Rcuxx::RcuMemory::Commit	(	size_t	off,
		size_t	n
	)			[inline, virtual]

Write to the hardware (restricted).

Parameters:

	off	Where to start reading
	n	How many words to read

Returns:

0 on success, error code otherwise

Reimplemented in Rcuxx::RcuACL, and Rcuxx::RcuDMEM.

References fBase, fData, fRcu, fSize, and Rcuxx::Rcu::WriteMemory().

unsigned int Rcuxx::RcuMemory::Clear

(

)

[inline, virtual]

Clear memory.

Reimplemented in Rcuxx::RcuACL.

References Rcuxx::RcuCommand::Commit(), and fClear.

unsigned int Rcuxx::RcuMemory::Exec

(

unsigned int

arg

)

[inline, virtual]

Clear memory.

References Rcuxx::RcuCommand::Commit(), and fExec.

Referenced by Rcuxx::RcuIMEM::Execute().

unsigned int Rcuxx::RcuMemory::Abort

(

)

[inline, virtual]

Clear memory.

References Rcuxx::RcuCommand::Commit(), and fAbort.

bool Rcuxx::RcuMemory::Load

(

std::istream &

in

)

[inline, virtual]

Load a file into the cache.

Returns:

true on success, false otherwise

References fData.

bool Rcuxx::RcuMemory::Save

(

std::ostream &

out

)

[inline, virtual]

Save the cache to file.

Returns:

true on success, false otherwise

References fData.

void Rcuxx::RcuMemory::Zero

(

)

[inline, virtual]

Zero the memory.

Reimplemented in Rcuxx::RcuACL.

References fData.

Referenced by RcuMemory(), and Rcuxx::RcuACL::Zero().

unsigned int Rcuxx::RcuMemory::Size

(

)

const [inline]

Returns:

Get the size

References fSize.

Referenced by Rcuxx::RcuACTFEC::ACLSync(), and Rcuxx::RcuACTFEC::SyncToACL().

unsigned int Rcuxx::RcuMemory::Max

(

)

const [inline]

Returns:

maximum value of each entry

References fMax.

const Cache_t& Rcuxx::RcuMemory::Data

(

)

const [inline]

Returns:

Get the data

References fData.

Cache_t& Rcuxx::RcuMemory::Data

(

)

[inline]

Returns:

Get the data

Reimplemented in Rcuxx::RcuACL.

References fData.

void Rcuxx::RcuMemory::Set	(	size_t	off,
		size_t	n,
		unsigned int *	d
	)			[inline]

Set the cache.

Parameters:

	off	Starting offset
	n	How many words (size of d)
	d	The values Set

Reimplemented in Rcuxx::RcuACL.

References fData, and fMax.

Referenced by Rcuxx::RcuIMEM::Append(), Rcuxx::RcuRegister::Commit(), Rcuxx::RcuACTFEC::Commit(), and Rcuxx::RcuACL::Set().

void Rcuxx::RcuMemory::Get	(	size_t	off,
		size_t	n,
		unsigned int *	d
	)			[inline]

Get the cache.

Parameters:

	off	Starting offset
	n	How many words (size of d)
	d	On return, the values

Reimplemented in Rcuxx::RcuACL.

References fData, and fMax.

Referenced by Rcuxx::RcuACL::Get(), Rcuxx::RcuRegister::Update(), and Rcuxx::RcuACTFEC::Update().

unsigned int Rcuxx::RcuMemory::Base

(

)

const [inline]

Get the base address.

References fBase.

Referenced by Rcuxx::RcuRegister::Print().

void Rcuxx::RcuMemory::Print

(

)

const [inline, virtual]

Print cache to standard output.

Reimplemented in Rcuxx::RcuACL, and Rcuxx::RcuSTATUS.

Examples:

rwr_trcfg.cxx.

References fData, and fName.

const std::string& Rcuxx::RcuMemory::Name

(

)

const [inline]

Get the name.

References fName.

virtual bool Rcuxx::RcuMemory::IsWriteable

(

)

const [inline, virtual]

Whether we got Clear.

References fWriteable.

virtual bool Rcuxx::RcuMemory::IsClearable

(

)

const [inline, virtual]

Whether we got Clear.

References fClear.

virtual bool Rcuxx::RcuMemory::IsExecutable

(

)

const [inline, virtual]

Whether we got Clear.

References fExec.

---

Member Data Documentation

Rcu& Rcuxx::RcuMemory::fRcu [protected]

Reference to RCU.

Referenced by Commit(), Rcuxx::RcuDMEM::Commit(), Rcuxx::RcuIMEM::Execute(), Rcuxx::RcuRMEM::FecCommand(), Rcuxx::RcuIMEM::FecCommand(), Rcuxx::RcuRMEM::FecRead(), Rcuxx::RcuIMEM::FecRead(), Rcuxx::RcuRMEM::FecWrite(), Update(), and Rcuxx::RcuDMEM::Update().

std::string Rcuxx::RcuMemory::fName [protected]

Name.

Referenced by Name(), Rcuxx::RcuSTATUS::Print(), and Print().

unsigned int Rcuxx::RcuMemory::fBase [protected]

Base address.

Referenced by Base(), Commit(), Rcuxx::RcuDMEM::Commit(), Update(), and Rcuxx::RcuDMEM::Update().

Cache_t Rcuxx::RcuMemory::fData [protected]

Data buffer.

Referenced by Rcuxx::RcuHEADER::Attributes(), Rcuxx::RcuHEADER::BlockLength(), Rcuxx::RcuHEADER::BunchCrossing(), Commit(), Rcuxx::RcuDMEM::Commit(), Rcuxx::RcuACL::Commit(), Data(), Rcuxx::RcuACL::Data(), Rcuxx::RcuIMEM::Execute(), Rcuxx::RcuRMEM::FecRead(), Rcuxx::RcuRMEM::FecWrite(), Rcuxx::RcuHEADER::FormatVersion(), Get(), Rcuxx::RcuHEADER::L1Message(), Load(), Rcuxx::RcuHEADER::MiniBunchCrossing(), Rcuxx::RcuHEADER::Orbit(), Print(), Rcuxx::RcuHEADER::RcuHEADER(), Rcuxx::RcuHEADER::RegionOfIntrest(), Save(), Set(), Rcuxx::RcuHEADER::SetAttributes(), Rcuxx::RcuHEADER::SetBlockLength(), Rcuxx::RcuHEADER::SetBunchCrossing(), Rcuxx::RcuHEADER::SetFormatVersion(), Rcuxx::RcuHEADER::SetL1Message(), Rcuxx::RcuHEADER::SetMiniBunchCrossing(), Rcuxx::RcuHEADER::SetOrbit(), Rcuxx::RcuHEADER::SetRegionOfIntrest(), Rcuxx::RcuHEADER::SetStatusErrors(), Rcuxx::RcuHEADER::SetSubDetectors(), Rcuxx::RcuHEADER::SetTriggerClasses(), Rcuxx::RcuHEADER::StatusErrors(), Rcuxx::RcuHEADER::SubDetectors(), Rcuxx::RcuHEADER::TriggerClasses(), Rcuxx::RcuSTATUS::Update(), Update(), Rcuxx::RcuDMEM::Update(), Rcuxx::RcuACL::Update(), and Zero().

unsigned int Rcuxx::RcuMemory::fSize [protected]

Size of the memory.

Referenced by Commit(), Rcuxx::RcuDMEM::Commit(), Rcuxx::RcuACL::Commit(), Size(), Rcuxx::RcuSTATUS::Update(), Update(), Rcuxx::RcuDMEM::Update(), and Rcuxx::RcuACL::Update().

unsigned int Rcuxx::RcuMemory::fMax [protected]

Max value of each entry in the memory.

Referenced by Get(), Max(), and Set().

bool Rcuxx::RcuMemory::fWriteable [protected]

Whether the memory is writeable.

Referenced by IsWriteable().

RcuCommand* Rcuxx::RcuMemory::fClear [protected]

Clear command, if any.

Referenced by Clear(), and IsClearable().

RcuCommand* Rcuxx::RcuMemory::fExec [protected]

Execute command, if any.

Referenced by Exec(), and IsExecutable().

RcuCommand* Rcuxx::RcuMemory::fAbort [protected]

Abort command, if any.

Referenced by Abort().

---

The documentation for this class was generated from the following file:

• RcuMemory.h
