slave Entity Reference

Inheritance diagram for slave:

[legend]

Collaboration diagram for slave:

[legend]

List of all members.

Architectures
rtl	Architecture
Libraries
ieee
Packages
std_logic_1164
fec_address_pack	Package <fec_address_pack>
serializer_bc_pack	Package <serializer_bc_pack>
slave_rx_pack	Package <slave_rx_pack>
slave_tx_pack	Package <slave_tx_pack>
sel_signals_pack	Package <sel_signals_pack>
Ports
clk	in std_logic
rstb	in std_logic
scl	in std_logic
sda_in	in std_logic
hadd	in std_logic_vector ( 4 downto 0 )
data_tx	in std_logic_vector ( 15 downto 0 )
bc_rst	in std_logic
csr1_clr	in std_logic
sda_out	out std_logic
reg_add	out std_logic_vector ( 6 downto 0 )
data_rx	out std_logic_vector ( 15 downto 0 )
slctr	out std_logic
we	out std_logic
ierr_sc	out std_logic
state	out std_logic_vector ( 10 downto 0 )

---

Member Data Documentation

bc_rst in std_logic [Port]

clk in std_logic [Port]

csr1_clr in std_logic [Port]

data_rx out std_logic_vector ( 15 downto 0 ) [Port]

data_tx in std_logic_vector ( 15 downto 0 ) [Port]

fec_address_pack package [Package]

hadd in std_logic_vector ( 4 downto 0 ) [Port]

ieee library [Library]

ierr_sc out std_logic [Port]

reg_add out std_logic_vector ( 6 downto 0 ) [Port]

rstb in std_logic [Port]

scl in std_logic [Port]

sda_in in std_logic [Port]

sda_out out std_logic [Port]

sel_signals_pack package [Package]

serializer_bc_pack package [Package]

slave_rx_pack package [Package]

slave_tx_pack package [Package]

slctr out std_logic [Port]

state out std_logic_vector ( 10 downto 0 ) [Port]

std_logic_1164 package [Package]

we out std_logic [Port]

---

The documentation for this class was generated from the following file:

• bc/bc_core/slave/slave.vhd
