msm_error_module Entity Reference

Inheritance diagram for msm_error_module:

[legend]

Collaboration diagram for msm_error_module:

[legend]

List of all members.

Architectures
rtl	Architecture
Libraries
ieee
Packages
std_logic_1164
numeric_std
Ports
clk	in std_logic
rstb	in std_logic
nack	in std_logic
seq_active	in std_logic
exec_in	in std_logic
bcast_dcs	in std_logic
branch_dcs	in std_logic
fec_add_dcs	in std_logic_vector ( 3 downto 0 )
fec_al	in std_logic_vector ( 31 downto 0 )
rst_errreg	in std_logic
errreg	out std_logic_vector ( 1 downto 0 )
exec_dcs	out std_logic

---

Member Data Documentation

bcast_dcs in std_logic [Port]

branch_dcs in std_logic [Port]

clk in std_logic [Port]

errreg out std_logic_vector ( 1 downto 0 ) [Port]

exec_dcs out std_logic [Port]

exec_in in std_logic [Port]

fec_add_dcs in std_logic_vector ( 3 downto 0 ) [Port]

fec_al in std_logic_vector ( 31 downto 0 ) [Port]

ieee library [Library]

nack in std_logic [Port]

numeric_std package [Package]

rst_errreg in std_logic [Port]

rstb in std_logic [Port]

seq_active in std_logic [Port]

std_logic_1164 package [Package]

---

The documentation for this class was generated from the following file:

• msmodule/msm_error_module/msm_error_module.vhd
