flex10ke_lcell Entity Reference

Inheritance diagram for flex10ke_lcell:

[legend]

Collaboration diagram for flex10ke_lcell:

[legend]

List of all members.

Architectures
vital_le_atom	Architecture
Libraries
IEEE
Packages
std_logic_1164
VITAL_Timing
VITAL_Primitives
atom_pack	Package <atom_pack>
Generics
operation_mode	string := " normal "
output_mode	string := " comb_and_reg "
clock_enable_mode	string := " false "
packed_mode	string := " false "
lut_mask	string := " ffff "
cin_used	string := " false "
x_on_violation	string := " on "
Ports
clk	in std_logic := ' 0 '
dataa	in std_logic := ' 1 '
datab	in std_logic := ' 1 '
datac	in std_logic := ' 1 '
datad	in std_logic := ' 1 '
aclr	in std_logic := ' 0 '
aload	in std_logic := ' 0 '
cin	in std_logic := ' 0 '
cascin	in std_logic := ' 1 '
devclrn	in std_logic := ' 1 '
devpor	in std_logic := ' 1 '
combout	out std_logic
regout	out std_logic
cout	out std_logic
cascout	out std_logic

---

Member Data Documentation

aclr in std_logic := ' 0 ' [Port]

aload in std_logic := ' 0 ' [Port]

atom_pack package [Package]

cascin in std_logic := ' 1 ' [Port]

cascout out std_logic [Port]

cin in std_logic := ' 0 ' [Port]

cin_used string := " false " [Generic]

clk in std_logic := ' 0 ' [Port]

clock_enable_mode string := " false " [Generic]

combout out std_logic [Port]

cout out std_logic [Port]

dataa in std_logic := ' 1 ' [Port]

datab in std_logic := ' 1 ' [Port]

datac in std_logic := ' 1 ' [Port]

datad in std_logic := ' 1 ' [Port]

devclrn in std_logic := ' 1 ' [Port]

devpor in std_logic := ' 1 ' [Port]

flex10ke_asynch_lcell package [Package]

Reimplemented from vital_le_atom.

flex10ke_lcell_register package [Package]

Reimplemented from vital_le_atom.

IEEE library [Library]

lut_mask string := " ffff " [Generic]

operation_mode string := " normal " [Generic]

output_mode string := " comb_and_reg " [Generic]

packed_mode string := " false " [Generic]

regout out std_logic [Port]

std_logic_1164 package [Package]

VITAL_Primitives package [Package]

VITAL_Timing package [Package]

x_on_violation string := " on " [Generic]

---

The documentation for this class was generated from the following file:

• flex10ke/flex10ke_atoms.vhd
