flex10ke_asynch_lcell Entity Reference

Inheritance diagram for flex10ke_asynch_lcell:

[legend]

Collaboration diagram for flex10ke_asynch_lcell:

[legend]

List of all members.

Architectures
vital_le	Architecture
Libraries
IEEE
Packages
std_logic_1164
VITAL_Timing
VITAL_Primitives
atom_pack	Package <atom_pack>
Generics
operation_mode	string := " normal "
output_mode	string := " comb_and_reg "
lut_mask	string := " ffff "
cin_used	string := " false "
TimingChecksOn	boolean := true
MsgOn	boolean := DefGlitchMsgOn
XOn	boolean := DefGlitchXOn
MsgOnChecks	boolean := DefMsgOnChecks
XOnChecks	boolean := DefXOnChecks
InstancePath	string := " * "
tpd_dataa_combout	vitaldelaytype01 := DefPropDelay01
tpd_datab_combout	vitaldelaytype01 := DefPropDelay01
tpd_datac_combout	vitaldelaytype01 := DefPropDelay01
tpd_datad_combout	vitaldelaytype01 := DefPropDelay01
tpd_qfbkin_combout	vitaldelaytype01 := DefPropDelay01
tpd_cin_combout	vitaldelaytype01 := DefPropDelay01
tpd_cascin_combout	vitaldelaytype01 := DefPropDelay01
tpd_dataa_regin	vitaldelaytype01 := DefPropDelay01
tpd_datab_regin	vitaldelaytype01 := DefPropDelay01
tpd_datac_regin	vitaldelaytype01 := DefPropDelay01
tpd_datad_regin	vitaldelaytype01 := DefPropDelay01
tpd_qfbkin_regin	vitaldelaytype01 := DefPropDelay01
tpd_cin_regin	vitaldelaytype01 := DefPropDelay01
tpd_cascin_regin	vitaldelaytype01 := DefPropDelay01
tpd_dataa_cout	vitaldelaytype01 := DefPropDelay01
tpd_datab_cout	vitaldelaytype01 := DefPropDelay01
tpd_datac_cout	vitaldelaytype01 := DefPropDelay01
tpd_datad_cout	vitaldelaytype01 := DefPropDelay01
tpd_qfbkin_cout	vitaldelaytype01 := DefPropDelay01
tpd_cin_cout	vitaldelaytype01 := DefPropDelay01
tpd_cascin_cascout	vitaldelaytype01 := DefPropDelay01
tpd_cin_cascout	vitaldelaytype01 := DefPropDelay01
tpd_dataa_cascout	vitaldelaytype01 := DefPropDelay01
tpd_datab_cascout	vitaldelaytype01 := DefPropDelay01
tpd_datac_cascout	vitaldelaytype01 := DefPropDelay01
tpd_datad_cascout	vitaldelaytype01 := DefPropDelay01
tpd_qfbkin_cascout	vitaldelaytype01 := DefPropDelay01
tipd_dataa	vitaldelaytype01 := DefPropDelay01
tipd_datab	vitaldelaytype01 := DefPropDelay01
tipd_datac	vitaldelaytype01 := DefPropDelay01
tipd_datad	vitaldelaytype01 := DefPropDelay01
tipd_cin	vitaldelaytype01 := DefPropDelay01
tipd_cascin	vitaldelaytype01 := DefPropDelay01
Ports
dataa	in std_logic := ' 1 '
datab	in std_logic := ' 1 '
datac	in std_logic := ' 1 '
datad	in std_logic := ' 1 '
cin	in std_logic := ' 0 '
cascin	in std_logic := ' 1 '
qfbkin	in std_logic := ' 0 '
combout	out std_logic
cout	out std_logic
cascout	out std_logic
regin	out std_logic
Attributes
VITAL_LEVEL0	TRUE

---

Member Data Documentation

atom_pack package [Package]

cascin in std_logic := ' 1 ' [Port]

cascout out std_logic [Port]

cin in std_logic := ' 0 ' [Port]

cin_used string := " false " [Generic]

combout out std_logic [Port]

cout out std_logic [Port]

dataa in std_logic := ' 1 ' [Port]

datab in std_logic := ' 1 ' [Port]

datac in std_logic := ' 1 ' [Port]

datad in std_logic := ' 1 ' [Port]

IEEE library [Library]

InstancePath string := " * " [Generic]

lut_mask string := " ffff " [Generic]

MsgOn boolean := DefGlitchMsgOn [Generic]

MsgOnChecks boolean := DefMsgOnChecks [Generic]

operation_mode string := " normal " [Generic]

output_mode string := " comb_and_reg " [Generic]

qfbkin in std_logic := ' 0 ' [Port]

regin out std_logic [Port]

std_logic_1164 package [Package]

TimingChecksOn boolean := true [Generic]

tipd_cascin vitaldelaytype01 := DefPropDelay01 [Generic]

tipd_cin vitaldelaytype01 := DefPropDelay01 [Generic]

tipd_dataa vitaldelaytype01 := DefPropDelay01 [Generic]

tipd_datab vitaldelaytype01 := DefPropDelay01 [Generic]

tipd_datac vitaldelaytype01 := DefPropDelay01 [Generic]

tipd_datad vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_cascin_cascout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_cascin_combout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_cascin_regin vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_cin_cascout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_cin_combout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_cin_cout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_cin_regin vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_dataa_cascout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_dataa_combout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_dataa_cout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_dataa_regin vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_datab_cascout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_datab_combout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_datab_cout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_datab_regin vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_datac_cascout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_datac_combout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_datac_cout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_datac_regin vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_datad_cascout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_datad_combout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_datad_cout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_datad_regin vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_qfbkin_cascout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_qfbkin_combout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_qfbkin_cout vitaldelaytype01 := DefPropDelay01 [Generic]

tpd_qfbkin_regin vitaldelaytype01 := DefPropDelay01 [Generic]

VITAL_LEVEL0 TRUE [Attribute]

Reimplemented from vital_le.

VITAL_Primitives package [Package]

VITAL_Timing package [Package]

XOn boolean := DefGlitchXOn [Generic]

XOnChecks boolean := DefXOnChecks [Generic]

---

The documentation for this class was generated from the following file:

• flex10ke/flex10ke_atoms.vhd
