bc_only Entity Reference
Inheritance diagram for bc_only:
Collaboration diagram for bc_only:
Architectures | |
| rtl | Architecture |
Libraries | |
| ieee | |
Packages | |
| std_logic_1164 | |
| bc_core_pack | Package <bc_core_pack> |
| drivers_pack | Package <drivers_pack> |
| altro_sw_mask_in_pack | Package <altro_sw_mask_in_pack> |
Ports | |
| clk | in std_logic |
| rstb | in std_logic |
| debug_sw | in std_logic |
| hadd | in std_logic_vector ( 4 downto 0 ) |
| sclk | in std_logic |
| scl | in std_logic |
| sda_in | in std_logic |
| otib | in std_logic |
| alps_errorb | in std_logic |
| l1b | in std_logic |
| l2b | in std_logic |
| al_dolo_enb | in std_logic |
| al_trsf_enb | in std_logic |
| paps_errorb | in std_logic |
| mscl | out std_logic |
| msda | inout std_logic |
| bc_int | out std_logic |
| altro_sw | out std_logic |
| pasa_sw | out std_logic |
| rdoclk_en | out std_logic |
| adcclk_en | out std_logic |
| adc_add0 | out std_logic |
| adc_add1 | out std_logic |
| test_a | out std_logic |
| test_b | out std_logic |
| test_c | out std_logic |
| test_d | out std_logic |
| test_e | out std_logic |
| test_f | out std_logic |
| test_g | out std_logic |
| test_h | out std_logic |
| sda_out | out std_logic |
| rst_fbc | out std_logic |
| bcout_ad | out std_logic_vector ( 4 downto 0 ) |
| oeba_l | out std_logic |
| oeab_l | out std_logic |
| oeba_h | out std_logic |
| oeab_h | out std_logic |
| ctr_in | out std_logic |
| ctr_out | out std_logic |
| bd | inout std_logic_vector ( 39 downto 0 ) |
| acknb | inout std_logic |
| errorb | inout std_logic |
| trsfb | inout std_logic |
| dstbb | inout std_logic |
| writeb | inout std_logic |
| cstbb | inout std_logic |
| mcst | out std_logic |
| tp_spare0 | out std_logic |
| tp_spare2 | out std_logic |
| tp_spare3 | out std_logic |
| tp_spare4 | out std_logic |
| tp_spare5 | out std_logic |
Member Data Documentation
acknb inout std_logic [Port] |
adc_add0 out std_logic [Port] |
adc_add1 out std_logic [Port] |
adcclk_en out std_logic [Port] |
al_dolo_enb in std_logic [Port] |
al_trsf_enb in std_logic [Port] |
alps_errorb in std_logic [Port] |
altro_sw out std_logic [Port] |
altro_sw_mask_in_pack package [Package] |
bc_core_pack package [Package] |
bc_int out std_logic [Port] |
bcout_ad out std_logic_vector ( 4 downto 0 ) [Port] |
bd inout std_logic_vector ( 39 downto 0 ) [Port] |
clk in std_logic [Port] |
cstbb inout std_logic [Port] |
ctr_in out std_logic [Port] |
ctr_out out std_logic [Port] |
debug_sw in std_logic [Port] |
drivers_pack package [Package] |
dstbb inout std_logic [Port] |
errorb inout std_logic [Port] |
hadd in std_logic_vector ( 4 downto 0 ) [Port] |
ieee library [Library] |
l1b in std_logic [Port] |
l2b in std_logic [Port] |
mcst out std_logic [Port] |
mscl out std_logic [Port] |
msda inout std_logic [Port] |
oeab_h out std_logic [Port] |
oeab_l out std_logic [Port] |
oeba_h out std_logic [Port] |
oeba_l out std_logic [Port] |
otib in std_logic [Port] |
paps_errorb in std_logic [Port] |
pasa_sw out std_logic [Port] |
rdoclk_en out std_logic [Port] |
rst_fbc out std_logic [Port] |
rstb in std_logic [Port] |
scl in std_logic [Port] |
sclk in std_logic [Port] |
sda_in in std_logic [Port] |
sda_out out std_logic [Port] |
std_logic_1164 package [Package] |
test_a out std_logic [Port] |
test_b out std_logic [Port] |
test_c out std_logic [Port] |
test_d out std_logic [Port] |
test_e out std_logic [Port] |
test_f out std_logic [Port] |
test_g out std_logic [Port] |
test_h out std_logic [Port] |
tp_spare0 out std_logic [Port] |
tp_spare2 out std_logic [Port] |
tp_spare3 out std_logic [Port] |
tp_spare4 out std_logic [Port] |
tp_spare5 out std_logic [Port] |
trsfb inout std_logic [Port] |
writeb inout std_logic [Port] |
The documentation for this class was generated from the following file:
- bc/bc_only.vhd
