msm_master Entity Reference

Inheritance diagram for msm_master:

Collaboration diagram for msm_master:

Architectures
rtl	Architecture
Libraries
ieee
msmodule_lib
Packages
std_logic_1164
msm_serializer_rcu_pack	Package <msm_serializer_rcu_pack>
msm_master_sm_pack	Package <msm_master_sm_pack>
msm_sync_pack	Package <msm_sync_pack>
Ports
clk	in std_logic
rstb	in std_logic
do_im	in std_logic_vector ( 7 downto 0 )
new_data	in std_logic
read	in std_logic
write	in std_logic
start	in std_logic
stop	in std_logic
sda_out	in std_logic
sda_ack	in std_logic
ready_seq	out std_logic
data_valid	out std_logic
error	out std_logic
scl	out std_logic
sda_in	out std_logic
master_end	out std_logic
cnt_rx	out std_logic
data_fbc	out std_logic_vector ( 7 downto 0 )

Member Data Documentation

clk in std_logic [Port]

cnt_rx out std_logic [Port]

data_fbc out std_logic_vector ( 7 downto 0 ) [Port]

data_valid out std_logic [Port]

do_im in std_logic_vector ( 7 downto 0 ) [Port]

error out std_logic [Port]

ieee library [Library]

master_end out std_logic [Port]

msm_master_sm_pack package [Package]

msm_serializer_rcu_pack package [Package]

msm_sync_pack package [Package]

msmodule_lib library [Library]

new_data in std_logic [Port]

read in std_logic [Port]

ready_seq out std_logic [Port]

rstb in std_logic [Port]

scl out std_logic [Port]

sda_ack in std_logic [Port]

sda_in out std_logic [Port]

sda_out in std_logic [Port]

start in std_logic [Port]

std_logic_1164 package [Package]

stop in std_logic [Port]

write in std_logic [Port]
