msm2_msmodule Entity Reference

Inheritance diagram for msm2_msmodule:

Collaboration diagram for msm2_msmodule:

Architectures
ARCH_MSM	Architecture
Libraries
IEEE
msmodule2_lib
Packages
STD_LOGIC_1164
msm2_interface_i2c_pack	Package <msm2_interface_i2c_pack>
msm2_decoder_pack	Package <msm2_decoder_pack>
Ports
rst	in std_logic
clk	in std_logic
wen_dcs	in std_logic
addr_dcs	in std_logic_vector ( 15 downto 0 )
data_dcs	in std_logic_vector ( 31 downto 0 )
dat_out_dcs	out std_logic_vector ( 31 downto 0 )
fec_act_list	in std_logic_vector ( 31 downto 0 )
rcu_version	in std_logic_vector ( 31 downto 0 )
err_reg_a	in std_logic_vector ( 31 downto 0 )
err_reg_b	in std_logic_vector ( 31 downto 0 )
sda_in_A	in std_logic
sda_out_A	out std_logic
s_clk_A	out std_logic
interruptA_in	in std_logic
warningTOdcs	out std_logic
interruptB_in	in std_logic
sda_in_B	in std_logic
sda_out_B	out std_logic
s_clk_B	out std_logic

Member Data Documentation

addr_dcs in std_logic_vector ( 15 downto 0 ) [Port]

clk in std_logic [Port]

dat_out_dcs out std_logic_vector ( 31 downto 0 ) [Port]

data_dcs in std_logic_vector ( 31 downto 0 ) [Port]

err_reg_a in std_logic_vector ( 31 downto 0 ) [Port]

err_reg_b in std_logic_vector ( 31 downto 0 ) [Port]

fec_act_list in std_logic_vector ( 31 downto 0 ) [Port]

IEEE library [Library]

interruptA_in in std_logic [Port]

interruptB_in in std_logic [Port]

msm2_decoder_pack package [Package]

msm2_interface_i2c_pack package [Package]

msmodule2_lib library [Library]

rcu_version in std_logic_vector ( 31 downto 0 ) [Port]

rst in std_logic [Port]

s_clk_A out std_logic [Port]

s_clk_B out std_logic [Port]

sda_in_A in std_logic [Port]

sda_in_B in std_logic [Port]

sda_out_A out std_logic [Port]

sda_out_B out std_logic [Port]

STD_LOGIC_1164 package [Package]

warningTOdcs out std_logic [Port]

wen_dcs in std_logic [Port]
