msm2_interface_I2C Entity Reference

Inheritance diagram for msm2_interface_I2C:

[legend]

Collaboration diagram for msm2_interface_I2C:

[legend]

List of all members.

Architectures
ARCH_interface_I2C	Architecture
Libraries
IEEE
msmodule2_lib
Packages
STD_LOGIC_1164
msm2_clk_div_pack	Package <msm2_clk_div_pack>
msm2_fsm_i2c_pack	Package <msm2_fsm_i2c_pack>
msm2_mux_dec_pack	Package <msm2_mux_dec_pack>
msm2_reg_so_pack	Package <msm2_reg_so_pack>
msm2_sipo_pack	Package <msm2_sipo_pack>
msm2_st_bit_cnt_pack	Package <msm2_st_bit_cnt_pack>
Ports
rst	in std_logic
clk	in std_logic
exec	in std_logic
rd_nwr	in std_logic
ld_regs	in std_logic
fec_add	in std_logic_vector ( 3 downto 0 )
bc_reg_add	in std_logic_vector ( 7 downto 0 )
B1_din	in std_logic_vector ( 7 downto 0 )
B2_din	in std_logic_vector ( 7 downto 0 )
rst_rslt	in std_logic
sv_rslt	out std_logic
sda_in_B1	out std_logic_vector ( 7 downto 0 )
sda_in_B2	out std_logic_vector ( 7 downto 0 )
end_rd	out std_logic
I2C_BSY	out std_logic
err_fec_ack	out std_logic
err_bc_add	out std_logic
err_din1_ack	out std_logic
err_din2_ack	out std_logic
fsm_state	out std_logic_vector ( 7 downto 0 )
bcast	in std_logic
sda_in	in std_logic
sda_out	out std_logic
s_clk	out std_logic

---

Member Data Documentation

B1_din in std_logic_vector ( 7 downto 0 ) [Port]

B2_din in std_logic_vector ( 7 downto 0 ) [Port]

bc_reg_add in std_logic_vector ( 7 downto 0 ) [Port]

bcast in std_logic [Port]

clk in std_logic [Port]

end_rd out std_logic [Port]

err_bc_add out std_logic [Port]

err_din1_ack out std_logic [Port]

err_din2_ack out std_logic [Port]

err_fec_ack out std_logic [Port]

exec in std_logic [Port]

fec_add in std_logic_vector ( 3 downto 0 ) [Port]

fsm_state out std_logic_vector ( 7 downto 0 ) [Port]

I2C_BSY out std_logic [Port]

IEEE library [Library]

ld_regs in std_logic [Port]

msm2_clk_div_pack package [Package]

msm2_fsm_i2c_pack package [Package]

msm2_mux_dec_pack package [Package]

msm2_reg_so_pack package [Package]

msm2_sipo_pack package [Package]

msm2_st_bit_cnt_pack package [Package]

msmodule2_lib library [Library]

rd_nwr in std_logic [Port]

rst in std_logic [Port]

rst_rslt in std_logic [Port]

s_clk out std_logic [Port]

sda_in in std_logic [Port]

sda_in_B1 out std_logic_vector ( 7 downto 0 ) [Port]

sda_in_B2 out std_logic_vector ( 7 downto 0 ) [Port]

sda_out out std_logic [Port]

STD_LOGIC_1164 package [Package]

sv_rslt out std_logic [Port]

---

The documentation for this class was generated from the following file:

• msmodule2/msm2_interface_i2c/msm2_interface_i2c.vhd
