msm2_fsm_i2c Entity Reference

Inheritance diagram for msm2_fsm_i2c:

[legend]

Collaboration diagram for msm2_fsm_i2c:

[legend]

List of all members.

Architectures
ARCH_fsm_i2c	Architecture
Libraries
IEEE
Packages
STD_LOGIC_1164
Ports
rst	in std_logic
clk	in std_logic
exec	in std_logic
rd_nwr	in std_logic
sda_in	in std_logic
bit_cnt_ovr	in std_logic
sclK	out std_logic
sel_sda_out	out std_logic_vector ( 2 downto 0 )
sda_out_fsm	out std_logic
sv_data_b1	out std_logic
sv_data_b2	out std_logic
en_fec_reg	out std_logic
en_bc_reg	out std_logic
en_B1_dout	out std_logic
en_B2_dout	out std_logic
en_cnt_in	out std_logic
cnt_in_ovr	in std_logic
err_fec_ack	out std_logic
err_bc_add	out std_logic
err_din1_ack	out std_logic
err_din2_ack	out std_logic
sv_rslt	out std_logic
I2C_BSY	out std_logic
end_rd	out std_logic
fsm_state	out std_logic_vector ( 7 downto 0 )
en_bit_cnt	out std_logic
clr_bit_cnt	out std_logic

---

Member Data Documentation

bit_cnt_ovr in std_logic [Port]

clk in std_logic [Port]

clr_bit_cnt out std_logic [Port]

cnt_in_ovr in std_logic [Port]

en_B1_dout out std_logic [Port]

en_B2_dout out std_logic [Port]

en_bc_reg out std_logic [Port]

en_bit_cnt out std_logic [Port]

en_cnt_in out std_logic [Port]

en_fec_reg out std_logic [Port]

end_rd out std_logic [Port]

err_bc_add out std_logic [Port]

err_din1_ack out std_logic [Port]

err_din2_ack out std_logic [Port]

err_fec_ack out std_logic [Port]

exec in std_logic [Port]

fsm_state out std_logic_vector ( 7 downto 0 ) [Port]

I2C_BSY out std_logic [Port]

IEEE library [Library]

rd_nwr in std_logic [Port]

rst in std_logic [Port]

sclK out std_logic [Port]

sda_in in std_logic [Port]

sda_out_fsm out std_logic [Port]

sel_sda_out out std_logic_vector ( 2 downto 0 ) [Port]

STD_LOGIC_1164 package [Package]

sv_data_b1 out std_logic [Port]

sv_data_b2 out std_logic [Port]

sv_rslt out std_logic [Port]

---

The documentation for this class was generated from the following file:

• msmodule2/msm2_interface_i2c/msm2_fsm_i2c/msm2_fsm_i2c.vhd
