counters Entity Reference

Inheritance diagram for counters:

[legend]

Collaboration diagram for counters:

[legend]

List of all members.

Architectures
rtl	Architecture
rtl2	Architecture
Libraries
ieee
Packages
std_logic_1164
triggercounter_pack	Package <triggercounter_pack>
dstb_counter_pack	Package <dstb_counter_pack>
sclk_counter_pack	Package <sclk_counter_pack>
Ports
clk	in std_logic
sclk	in std_logic
rstb	in std_logic
clr_cnt	in std_logic
l0_trg	in std_logic
l1_trg	in std_logic
l2_trg	in std_logic
csr3	in std_logic_vector ( 7 downto 0 )
adcclk_en	in std_logic
dstb	in std_logic
al_trsf	in std_logic
l0_cnt	out std_logic_vector ( 15 downto 0 )
l1_cnt	out std_logic_vector ( 15 downto 0 )
l2_cnt	out std_logic_vector ( 15 downto 0 )
sclk_cnt	out std_logic_vector ( 15 downto 0 )
missed_sclk	out std_logic
dstb_cnt	out std_logic_vector ( 7 downto 0 )

---

Member Data Documentation

adcclk_en in std_logic [Port]

al_trsf in std_logic [Port]

clk in std_logic [Port]

clr_cnt in std_logic [Port]

csr3 in std_logic_vector ( 7 downto 0 ) [Port]

dstb in std_logic [Port]

dstb_cnt out std_logic_vector ( 7 downto 0 ) [Port]

dstb_counter_pack package [Package]

ieee library [Library]

l0_cnt out std_logic_vector ( 15 downto 0 ) [Port]

l0_trg in std_logic [Port]

l1_cnt out std_logic_vector ( 15 downto 0 ) [Port]

l1_trg in std_logic [Port]

l2_cnt out std_logic_vector ( 15 downto 0 ) [Port]

l2_trg in std_logic [Port]

missed_sclk out std_logic [Port]

rstb in std_logic [Port]

sclk in std_logic [Port]

sclk_cnt out std_logic_vector ( 15 downto 0 ) [Port]

sclk_counter_pack package [Package]

std_logic_1164 package [Package]

triggercounter_pack package [Package]

---

The documentation for this class was generated from the following file:

• bc/bc_core/registers/counters/counters.vhd
